邮轮上层建筑新型结构设计及振动分析毕业论文

 2020-02-18 12:02

摘 要

邮轮原指航行于大洋的班轮、邮船客船,一般具有旅游性质,也是公认的“三高船舶”。其中大型豪华邮轮与大型液化天然气船(LNG)、航空母舰并称为“全球造船业皇冠上的三颗明珠”。我国已成功摘下其中的两颗,但攻克大型豪华邮轮的难度还很大。与其他传统的主流船型相比,邮轮的建造虽然也有规范和法规来规定它的强度和安全,但由于其功能的特殊性即向游客提供高端服务,规范无法约束其结构造型。邮轮除具备一般客轮的基本功能外,还提供专门的观景、娱乐设施和服务项目以满足乘客的需求,所以邮轮的安全性、舒适性等是至关重要,因此对于大型邮轮的振动研究有非常重要的意义。

本文就邮轮上层建筑典型局部结构进行分析,利用有限元法计算单层甲板在不同的边界条件、板厚等条件下的模态变化。利用点载荷代替人体重力,计算在不同人流密度和分布条件对顶层甲板振动频率和模态的影响。在此基础下细化计算小板架腹板开孔与否、开孔形状不同和开孔率不同对板架模态计算的影响。以邮轮中央大厅的甲板局部结构为研究对象,建立中央大厅四层甲板的有限元模型,并应用有限元计算分析其振动特性,对每层甲板的垂向振动进行分析。

关键词:有限元法;稳态响应;邮轮上层建筑;腹板开孔

Abstract

Cruise ship originally refers to liner, postal ship and passenger ship sailing in the ocean, generally has the nature of tourism, and is recognized as the "three high ship". Among them, large luxury cruise ships, large liquefied natural gas ships (LNG) and aircraft carriers are called "the three pearls in the crown of the global shipbuilding industry". China has successfully picked off two of them, but it is still very difficult to conquer large luxury cruise ships. Compared with other traditional mainstream ship types, although the construction of cruise ships also has norms and regulations to stipulate its strength and safety, due to the particularity of its function, which is to provide high-end services to tourists, the norms cannot constrain its structure and shape. In addition to the basic functions of ordinary passenger ships, cruise ships also provide special viewing facilities, entertainment facilities and service items to meet the needs of passengers. Therefore, the safety and comfort of cruise ships are of vital importance. Therefore, it is of great significance to study the vibration of large cruise ships.

In this paper, the typical local structure of cruise superstructure is analyzed, and the modal changes of single deck under different boundary conditions and plate thickness are calculated by finite element method. The effects of different crowd density and distribution conditions on the vibration frequency and mode of the top deck are calculated by using point load instead of human gravity. On the basis of this, the influences of the perforation, the different shape of the perforation and the different rate of the perforation on the modal calculation of the plate frame are refined. Taking the partial deck structure of the cruise ship central hall as the research object, the finite element model of the four decks of the central hall was established, and the vibration characteristics of the four decks were analyzed by using the finite element method, and the vertical vibration of each deck was analyzed.

Key Words:FEM; Steady-state response; the superstructure of the cruise;the web opening
